Hydraulic Accumulators
Hydraulic Accumulators are provided by Kocsis Technologies Inc. We have many reasons to trust and rely on KTI. Here are just a few of the many reasons to choose Roy Supply and KTI for your specialty accumulators:
- KTI has more that a quarter century designing and manufacturing pressure vessels
- 20+ years of subsea accumulator experience
- Extensive understanding of third party approvals
- Hydrostatic testing capability up to 120,000 PSI
- ISO 9001 Certified
- State-of-the-art underground test facility
- Lifting capabilities of 50 tons
- In-house Custom Accumulator manufacturing from 1 QT to 400 GAL
- Standard Bladder and Piston Accumulator line up
- Global Network of Distribution
- Sister company Kocsis Brothers Machine Co. is one of the larges machine shops in the country
- Engineering driven with a focus on innovation through prototyping and testing
General Uses for Accumulators:
- Energy Storage Device: Accumulators are used to store potential energy in a similar manner as a battery, but without the adverse effects of losing charge over time due to sitting or cold temperatures.
- Pulsation Dampening: Accumulators are used to cushion sudden pressure spikes in a system that causes the effect know as "water hammering."
- Pump Supplementation: Accumulators can be used to help assist with pump flow allowing for smaller pumps to be used in a system reducing head and energy costs.
- Auxiliary Power Source: Accumulators store oil delivered by a pump during the working cycle. The accumulator then releases that stored oil on demand during pump dwell.
- Thermal Expansion Device: Accumulators can be used to store fluid in a system when it expands due to heat or provide fluid when the system cools.
- Fluid Dispenser (under pressure): Accumulators can also be used to dispense fluid into the system to make up for fluid loss from normal operation of components, such as valves or cylinders.
Industries Served:
- Oil and Gas
- Power Generation
- Mining
- Wind Power
- Entertainment
- Steel
- Agriculture
- Defense
- Marine
- Construction
|
PISTON ACCUMULATORS STANDARD LINE |
|
|---|---|
| 3,000 PSI | CAPACITIES |
| 4.0 INCH BORE | 1 QT - 3 GAL |
| 6.0 INCH BORE | 1 GAL - 10 GAL |
| 7.0 INCH BORE | 5 GAL - 20 GAL |
| 9.0 INCH BORE | 10 GAL - 30 GAL |
| 12.0 INCH BORE | 20 GAL -50 GAL |
| 5,000 PSI | CAPACITIES |
| 4.0 INCH BORE | 1 QT - 3 GAL |
| 6.0 INCH BORE | 1 GAL - 10 GAL |
| 7.0 INCH BORE | 5 GAL - 20 GAL |
| 9.0 INCH BORE | 10 GAL - 30 GAL |
| 10,000 PSI | CAPACITIES |
| 2.0 INCH BORE | 1 PINT, 1 QT, 1/2 GAL |
| 4.0 INCH BORE | 1/2 GAL, 1 GAL, 2 GAL |
| BLADDER ACCUMULATOR | |
|---|---|
| BOTTOM REPAIRABLE | CAPACITIES |
| 3,000 PSI | 1, 2.5, 5, 10, 11, 15 GAL |
| 6,000 PSI | 1, 2.5, 5, 10, 11, 15 GAL |
| TOP REPAIRABLE | CAPACITIES |
| 3,000 PSI | 1, 2.5, 5, 10, 11, 15 GAL |
| 6,000 PSI | 1, 2.5, 5, 10, 11, 15 GAL |
| CUSTOM PISTON ACCUMULATORS | ||||
|---|---|---|---|---|
| MATERIAL OPTIONS | NUMEROUS SEAL GEOMETRIES | APPROVALS | SEAL COMPOUNDS | CAPACITIES |
| ALUMINUM | T-SEALS | ASME | BUNA | FROM 1/2 PINT TO 400 GALLONS |
| CARBON STEEL | U-CUPS | CE | VITON | |
| STAINLESS STEEL | POLYSEALS | ABS/ABS-CDS | EPR | |
| DUPLEX | DNV | HYTRLE | ||
| SUPER DUPLEX | CRN | LOW-TEMP BUNA | ||
| NR-13 | ||||
